Description
|
Brand |
York |
|
Cut Type |
Cut 6 – Double Cut |
|
EAN |
5036140216723 |
|
ECLASS Code |
21010101 |
|
Finish/Coating |
Uncoated |
|
Head Diameter |
10mm |
|
Head Length |
19mm |
|
Head Material |
Carbide |
|
Head Shape |
Cylindrical End Cut |
|
Included Angle |
90° |
|
Overall Length |
65mm |
|
Shank Diameter |
6mm |
|
UNSPSC Code |
23251706 |
Cut 6 – Double Cut. Crosscut and double cut to improve control and chipbreaks. Manufactured from high grade tungsten carbide for general-purpose use. Suitable for deburring and polishing of cast iron, cast steel, carbon steel, alloy steel and stainless steel etc up to HRC65 hardness
Features and Benefits
- Manufactured from high grade tungsten carbide for improved toughness
- Crosscut and double cut to improve control and chipbreaks
Typical Applications
- Deburring
- Polishing
- Cast iron
- Cast steel
- Carbon steel
- Alloy steel
- Stainless steel
Notes
- Work piece and tools should always be steady and well supported
- Carbide burrs are not suitable for ‘milling’ large amounts of material, they are for light stock removal and high revolutions’LOW FEED – HIGH SPEED’
- Always ensure that at least 70% of the shank length is clamped by the collet or chuck of the tool being used
- Always ensure that the tool is rated to the recommended operating speed of the burr
