Description
The Prime X-Coated range from YG-1 are the number 1 universal machine taps for high performance machining. With up to 50% higher cutting speeds and 100% more tool life than HSSE taps, Prime X-Coated are ideal for universal performance tapping a wide range of materials including steel, stainless steel, cast iron, exotics and non-ferrous. These are ultra reliable due to the special thread structure which reduces torque and prevents overfeeding. The premium powder metal substrate ensures a tough chip resistant cutting edge, whilst the unique X-coating offers high heat and wear resistance. The TRJ17 series has a spiral point geometry suitable for tapping through holes. Made by YG-1 from South Korea, the global market leading manufacturer of cutting tools.
Features & Benefits
- Number 1 for all round high performance machine tapping a wide range of materials.
- Up to 50% higher cutting speeds and 100% more tool life than HSSE taps.
- Spiral point geometry for through holes.
- Ultra reliable due to the patented design which prevents over feeding & premature tap failure.
- Premium powder metal substrate provides a tough chip resistant cutting edge.
- YG-1’s unique X-coating ensures heat and wear resistance in performance tapping.
- Ideal for steel, stainless steel, cast iron, exotics and non-ferrous.
- Made by YG-1 from South Korea, the global market leading manufacturer of cutting tools.
Specification
| Category | Threading | Sub Category | Machine Taps | Thread | 1″ | Sub Category 2 | High Performance Universal Machine Taps | Shank (mm) | 20 | Flute Length (mm) | 36 | Overall Length (mm) | 160 | TPI | 8 | Flutes | 3 | L3 | 60 | Drill Diameter | 22.25 | Square | 16 | Substrate | HSS-PM | Oil Grooves | No | Surface Treatment | Coated (PVD/CVD) | Depth | 3xD | Applicable Materials | Steel, Stainless Steel, Cast Iron, Non-Ferrous | Flute Geometry | Spiral Point | Performance | 5 | Coating Description | X Coated | Through Coolant | No | Substrate Description | HSS Powder Metal | Helix Angle | 60° | Brand Range | Prime-X | Thread Form | UNC (Unified Coarse) | Chamfer Lead | Form B (with Spiral Point and Chamfer Lead 4-5 Thread) | Brand | YG-1 |
|---|
